Brachial Plexus MRI: Complete Guide to Imaging, Anatomy, Pathology, and Clinical Applications

Brachial plexus MRI has become the gold standard imaging modality for evaluating complex nerve network injuries, tumors, and inflammatory conditions affecting the shoulder and upper extremity. The brachial plexus is a remarkably intricate web of nerve roots arising from C5 through T1, weaving together to form the major nerves that control arm, hand, and shoulder function. When something goes wrong with this network — whether from trauma, tumor infiltration, or radiation damage — MRI provides the anatomical detail necessary to guide surgical planning and predict patient outcomes.

Understanding the technical demands of brachial plexus mri is essential for MRI technologists and radiologists alike. Unlike routine spine or extremity imaging, brachial plexus studies require specialized coil configurations, precise patient positioning, and a thorough knowledge of regional anatomy. The nerves course through multiple fascial compartments and fat planes, making high-resolution, high-contrast imaging absolutely critical. A suboptimal scan can obscure a surgically correctable lesion or delay a cancer diagnosis by months.

In clinical practice, brachial plexus MRI is ordered for a diverse range of presentations. Trauma patients who present after motorcycle accidents, birth injuries, or sports collisions may have traction injuries ranging from mild neuropraxia to devastating avulsion from the spinal cord. Oncology patients with breast, lung, or lymphoma diagnoses may develop plexopathy from direct tumor invasion or as a delayed consequence of radiation therapy. Differentiating malignant from radiation-induced plexopathy is one of the most clinically impactful roles that MRI plays in this anatomical region.

From a technical standpoint, brachial plexus imaging typically employs a 3 Tesla magnet to maximize signal-to-noise ratio, though high-quality studies can be performed at 1.5T with appropriate sequence optimization. Phased-array surface coils centered over the neck and shoulder are preferred, and many institutions combine a neurovascular coil with a spine coil to cover the full course of the plexus from the neural foramina to the infraclavicular fossa. Fat suppression techniques, including STIR and spectral fat saturation, are indispensable for highlighting edematous or infiltrated nerve fascicles.

The sequences that form the backbone of a brachial plexus MRI protocol are carefully chosen to answer specific clinical questions. Coronal STIR images provide an excellent overview of nerve signal and symmetry. Axial T1-weighted images map the anatomical relationships of the plexus to adjacent muscles, vessels, and lymph nodes. Three-dimensional isotropic sequences, such as SPACE or CUBE, allow multiplanar reformations and can be processed into neurography images that beautifully depict individual nerve fascicles. Diffusion-weighted neurography is an emerging technique that quantifies nerve microstructure through fractional anisotropy and apparent diffusion coefficient measurements.

For MRI technologists preparing for registry examinations or clinical practice, brachial plexus imaging represents a high-yield area that bridges anatomy, physics, and pathology. Knowing why each sequence is chosen — not just how to run it — is what distinguishes a competent technologist from an expert one. The interplay between repetition time, echo time, inversion recovery, and field strength directly determines whether a subtle nerve injury will be visible or missed, making technical mastery clinically consequential.

This comprehensive guide covers everything from brachial plexus anatomy and normal MRI appearances to pathology recognition, protocol design, patient preparation, and practical examination tips. Whether you are a student preparing for boards, a technologist expanding your clinical skills, or a clinician seeking to better understand what MRI can and cannot tell you about brachial plexus disease, this resource provides the depth and clarity you need.

Designing an effective brachial plexus MRI protocol requires balancing anatomical coverage, spatial resolution, and scan time — three variables that are perpetually in tension. The full plexus spans from the cervical neural foramina to the axillary fossa, a distance that may exceed 20 centimeters in a large patient. Covering this field of view while maintaining the submillimeter resolution needed to visualize individual fascicles demands thoughtful sequence selection and often requires two overlapping acquisitions with careful coil repositioning between stations.

Coronal plane imaging is the single most valuable orientation for brachial plexus assessment. A coronal STIR sequence with a large field of view captures the entire nerve network in just a few image slices, making it ideal for screening and for comparing the symptomatic and asymptomatic sides side by side. Nerve signal on STIR should be mildly hyperintense relative to muscle — markedly increased signal indicates edema, inflammation, or active injury. Asymmetric signal between sides is one of the most reliable indicators of pathology, even when individual nerve caliber appears normal.

T1-weighted sequences without fat suppression are indispensable for evaluating nerve caliber, fatty infiltration of muscles, and the relationship of masses to the plexus. On T1, normal nerves appear isointense to muscle with a faintly striated internal architecture corresponding to fascicular bundles. When a nerve is infiltrated by tumor, its internal architecture is replaced by homogeneous or irregular soft tissue signal. Perineural fibrosis from radiation or prior surgery appears as T1 isointense thickening that encases the nerve without the mass effect or T2 signal elevation seen with active tumor.

Three-dimensional isotropic sequences have transformed brachial plexus neurography over the past decade. Sequences marketed under vendor-specific names — SPACE (Siemens), CUBE (GE), VISTA (Philips) — acquire a single high-resolution volume that can be reconstructed in any plane post-acquisition. When combined with a background suppression technique such as DWIBS (diffusion-weighted whole-body imaging with background body signal suppression), these sequences produce striking maximum intensity projection images that highlight nerves against a dark background, dramatically improving the detection of focal lesions and architectural distortion.

Contrast-enhanced MRI with gadolinium plays a selective but important role in brachial plexus imaging. Normal peripheral nerves do not enhance, so avid or nodular enhancement strongly suggests an inflammatory process (such as Parsonage-Turner syndrome in the acute phase) or a neoplastic lesion. Perineural tumor spread from head and neck cancers can be elegantly mapped with fat-saturated T1 post-contrast sequences, showing enhancement tracking along nerve sheaths toward the neural foramina. However, gadolinium is not routinely administered for trauma cases where the clinical question is limited to mechanical injury.

Diffusion tensor imaging (DTI) and tractography represent the frontier of brachial plexus MRI. By measuring the directional diffusivity of water molecules along nerve fascicles, DTI can generate color-encoded fractional anisotropy maps and three-dimensional tractograms that visualize individual nerve fiber bundles. Studies comparing DTI metrics to surgical and electrophysiological findings show that fractional anisotropy drops significantly at sites of nerve injury, sometimes before conventional sequences reveal abnormality. While DTI is not yet standard of care, it is increasingly available at academic centers and will likely become routine within the next decade.

Patient positioning and coil selection are as important as sequence choice. Patients lie supine with the arm at the side in the neutral or slightly abducted position. Some protocols ask the patient to place the arm overhead in the swimmer's position to open the costoclavicular space and reduce vascular pulsation artifact near the subclavian vessels. A neurovascular phased-array coil centered over the ipsilateral neck and shoulder provides the best signal coverage for unilateral studies. For bilateral assessment, a large-field spine array or two overlapping coils positioned symmetrically across the upper chest and neck is preferred.

Interpreting a brachial plexus MRI requires a systematic approach that begins with clinical context and proceeds through each anatomical segment from root to terminal branch. Before reviewing images, the interpreting radiologist should know the patient's dominant hand, the mechanism and timing of injury or symptom onset, any prior surgeries or radiation fields, and the results of electrodiagnostic studies. This clinical correlation transforms image interpretation from pattern recognition into true diagnostic reasoning — the same finding may have very different implications in a trauma patient versus a breast cancer survivor.

Begin review with the coronal STIR sequence, which provides the clearest overview of plexus signal and symmetry. Systematically compare the affected side to the contralateral normal side at each level — roots, trunks, and cords. Note any focal or diffuse signal elevation, asymmetric nerve caliber, or complete nerve discontinuity. Pay particular attention to the supraclavicular plexus (roots and trunks), where traumatic traction injuries and most nerve sheath tumors occur, and to the infraclavicular plexus (cords and branches), where thoracic outlet compression and lymph node involvement are most commonly encountered.

Axial T1-weighted images are next, reviewed from the C4-5 disk level through the mid-axillary fossa. At each level, identify the expected nerve structures and assess whether they maintain their normal oval morphology, signal intensity, and relationship to adjacent anatomical landmarks. Asymmetric fatty replacement of muscles served by specific plexus segments provides powerful clues about the location and chronicity of injury. For example, isolated denervation of the serratus anterior (supplied by the long thoracic nerve, C5-7) suggests a specific nerve injury distinct from a complete trunk-level lesion.

Post-contrast T1 fat-saturated images should be reviewed with enhancement pattern as the primary diagnostic criterion. Normal nerve fascicles are not expected to enhance. Any enhancement within the expected nerve course demands explanation — possibilities include active inflammation (Parsonage-Turner syndrome), perineural tumor spread, or nerve sheath tumor. The distribution, avidity, and homogeneity of enhancement help narrow the differential. Thin, smooth perineural enhancement extending along multiple nerve segments toward the foramina is highly suggestive of perineural tumor spread from a head and neck primary.

Three-dimensional neurography images, when available, should be reviewed as maximum intensity projections and multiplanar reformations rather than exclusively as source images. The MIP images depict the nerve network as a branching structure similar to an angiogram, making it immediately apparent when a segment is absent, focally thickened, or displaced by an adjacent mass. Source images, however, are essential for characterizing internal nerve architecture, assessing fascicular detail, and measuring lesion dimensions for surgical planning or follow-up comparison.

DTI-derived metrics add a quantitative dimension to brachial plexus assessment that is particularly valuable for longitudinal monitoring. In healthy peripheral nerves, fractional anisotropy values typically range from 0.4 to 0.7, reflecting the highly organized parallel arrangement of axons. At sites of compression, crush injury, or inflammation, FA drops significantly — sometimes to values below 0.2. Mean diffusivity, conversely, tends to rise at injury sites as the ordered microstructure breaks down and water diffusion becomes less restricted and more isotropic. Tracking these metrics on serial studies correlates better with clinical recovery than conventional sequence findings in some published series.

Reporting a brachial plexus MRI requires structured communication that directly addresses the clinical question. A useful report format identifies the affected plexus segment (using standard anatomical nomenclature), characterizes the MRI findings at that level (signal change, caliber, morphology, enhancement), identifies target muscle denervation changes and their chronicity, and provides a differential diagnosis ranked by probability given the clinical context. For surgical cases, explicitly state whether the injury is preganglionic or postganglionic, as this distinction fundamentally determines operative strategy — avulsion cannot be repaired at the root level and requires nerve transfer procedures from intact donor nerves.

For MRI technologists and students preparing for the ARRT registry examination, brachial plexus imaging represents a convergence of anatomy, physics, and pathology that is heavily tested across multiple content domains. The ability to name and locate each component of the plexus — roots, trunks, divisions, cords, and terminal branches — is foundational. Equally important is understanding the dermatomal and myotomal distributions of each root level, since denervation changes in specific muscle groups on MRI directly map to root-level localization.

On the registry examination, MRI physics questions related to brachial plexus imaging most commonly address fat suppression techniques and their trade-offs. STIR suppresses fat by exploiting its short T1 relaxation time using an inversion recovery pulse, making it insensitive to B0 field inhomogeneity — a major advantage in the neck where field distortion is significant near air-tissue interfaces.

Spectral fat saturation (CHESS or SPIR) uses a frequency-selective pulse to null fat signal and is faster than STIR but fails at regions of field inhomogeneity, which is precisely why STIR is preferred for brachial plexus imaging despite its lower signal-to-noise ratio and longer acquisition time.

Understanding the clinical rationale for gadolinium in brachial plexus imaging is another registry-relevant concept. The blood-nerve barrier, analogous to the blood-brain barrier, normally prevents gadolinium from entering the endoneurial compartment of healthy peripheral nerves. Breakdown of this barrier in inflammation or tumor invasion allows contrast to accumulate within the nerve, producing visible enhancement. This physiological principle explains why enhancement is always pathological in a peripheral nerve context and why non-contrast sequences are sufficient for most traumatic plexus injuries where inflammatory breakdown of the blood-nerve barrier is not the primary diagnostic concern.

Motion artifact management is a key technical skill that registry candidates should master conceptually. Cardiac and respiratory motion propagates as ghosting artifact in the phase-encoding direction and can obscure plexus anatomy in the axillary and supraclavicular regions. Technologists use multiple strategies to minimize this artifact: placing the phase-encoding direction in the foot-head orientation (so breathing motion ghosts away from the plexus), applying spatial saturation bands over the chest and heart, using respiratory gating or triggering for sensitive sequences, and prescribing cardiac gating for axial sequences at the level of the subclavian vessels.

Gradient coil performance and its relationship to resolution is another physics concept relevant to neurography. Achieving sub-millimeter in-plane resolution requires strong, fast-switching gradients that generate maximum amplitude slew rates. Modern 3T systems designed for neurography can achieve gradient amplitudes of 80 mT/m or higher, enabling the short echo spacing necessary for high-resolution 3D SPACE or CUBE acquisitions without excessive T2 blurring. Understanding why resolution has improved so dramatically over the past decade requires appreciating these hardware advances — not just the sequence design.

Contraindication screening for brachial plexus patients deserves special mention because this population often includes trauma victims who may be unconscious, intoxicated, or unable to provide an accurate implant history. Institutional protocols for emergent MRI in unresponsive patients typically require rapid x-ray screening of the chest and potentially the orbital region to exclude ferromagnetic foreign bodies. Peripheral nerve stimulators and spinal cord stimulators — increasingly common in chronic pain patients — require individual implant verification before 3T scanning and may necessitate downgrade to 1.5T or exclusion from MRI entirely depending on device labeling.

For exam candidates, the most effective way to solidify brachial plexus knowledge is to practice with case-based questions that integrate anatomy, physics, and pathology into realistic clinical scenarios. Knowing that a pseudomeningocele indicates root avulsion is useful, but knowing why — the dural sleeve tears, CSF extravasates laterally through the foramina, and the displaced nerve root loses its connection to the cord — is what cements the concept and allows application to novel cases. Active recall through quiz-based practice, rather than passive re-reading, is the evidence-based strategy that most efficiently converts knowledge into durable exam-ready understanding.

Practical success in brachial plexus MRI — whether measured by diagnostic yield, patient throughput, or examination performance — comes down to preparation, protocol discipline, and the habit of systematic review. The following practical tips represent the distilled wisdom of experienced MRI technologists and radiologists who have built high-volume brachial plexus imaging programs. Incorporating these practices into your workflow will improve image quality, reduce repeat examinations, and sharpen the diagnostic precision of your interpretations.

Always perform a brief pre-scan patient interview even when the order provides clinical history. Ask specifically which arm is symptomatic, whether symptoms are purely sensory or include weakness, how long symptoms have been present, and whether there has been any prior surgery or radiation to the neck or axilla. This two-minute conversation frequently reveals information not captured in the electronic order — a previous mastectomy, a forgotten prior MRI at another institution, or a history of childhood plexus birth injury — that directly changes which sequences you prioritize or which side you center the coil on.

For trauma cases, where patient cooperation may be limited, front-load the most diagnostically critical sequences. Acquire the coronal STIR and axial T2 or STIR sequences first, before the patient fatigues or becomes unable to cooperate with breath-hold instructions. Save the longer 3D neurography acquisitions for later in the protocol when they are less urgent. Having the two highest-yield sequences completed within the first fifteen minutes of scanning ensures that even a truncated examination yields actionable diagnostic information.

Optimizing fat suppression in the neck requires careful attention to shimming. After coil placement and patient positioning, always run the local shim over a volume that includes the entire plexus coverage area — from C4 to the axillary fold. A poorly shimmed volume will produce heterogeneous fat suppression that creates bright fat patches masquerading as nerve signal on STIR or creates dark signal dropout regions that mimic nerve injury on spectral fat-saturated sequences. Spending two extra minutes optimizing shim before acquiring fat-suppressed sequences consistently pays off in diagnostic quality.

When reviewing coronal neurography images, use the windowing controls actively rather than accepting the default display settings. Narrowing the window width to enhance nerve-to-background contrast often reveals subtle signal asymmetries that are invisible on default settings. Conversely, widening the window is useful for assessing the background tissue signal and ensuring that fat suppression is homogeneous across the field of view. Most PACS workstations allow saving custom window presets — creating a neurography-specific window preset for your institution saves time and ensures consistent display across readers.

Keep a personal log of interesting brachial plexus cases encountered in clinical practice or during study. Each case should record the clinical presentation, key MRI findings, final diagnosis, and one teaching point. Over time, this case library becomes an invaluable resource for registry preparation and for developing the pattern recognition skills that textbooks cannot fully convey. Reviewing twenty real cases of Parsonage-Turner syndrome — noting the variation in nerve segments affected, the presence or absence of enhancement, and the evolution of findings on follow-up — builds the experiential foundation that allows confident diagnosis in the clinical setting.

Collaboration between the MRI technologist and the radiologist before scanning complex cases improves outcomes measurably. A brief three-minute conversation about the clinical question — is this a trauma case where root avulsion needs exclusion, or an oncology case where perineural spread needs assessment — allows the technologist to intelligently adjust the protocol rather than running a generic default. At institutions where this practice is formalized through pre-scan radiologist sign-off on complex neurological studies, repeat examination rates for brachial plexus MRI drop significantly and referring physicians consistently report higher satisfaction with report actionability.

Finally, stay current with the rapidly evolving literature on brachial plexus neurography. New sequences, new post-processing techniques, and new clinical applications are published regularly. Following radiology journals focused on neuroradiology and musculoskeletal imaging, attending hands-on neurography workshops at major radiology meetings, and participating in online case-sharing communities are all effective strategies for maintaining expertise in a field where the state of the art advances faster than most textbooks can track. The combination of strong foundational knowledge — built through systematic study and registry-level preparation — with curiosity-driven continuous learning is what sustains excellence in brachial plexus MRI over a career.
