TOGAF 9 Foundation Certification — Questions and Answers

Question 1: What type of analysis is performed in each of Phases B, C, and D to identify shortfalls between current and target states?

Gap Analysis (Correct answer)
Cost-Benefit Analysis
SWOT Analysis
Risk Assessment

Correct answer: Gap Analysis

Gap Analysis in Phases B, C, and D identifies the differences between the Baseline and Target Architectures that must be addressed.

Question 2: What is the primary purpose of Architecture Governance in TOGAF?

To ensure that architectures are developed and evolved in a consistent and controlled way in line with enterprise goals (Correct answer)
To approve technology purchases
To control project budgets
To manage IT vendor relationships

Correct answer: To ensure that architectures are developed and evolved in a consistent and controlled way in line with enterprise goals

Architecture Governance ensures consistent, controlled architecture development aligned with enterprise objectives, IT strategy, and regulatory requirements.

Question 3: Why is it important for architects to understand stakeholders' 'time horizons' in TOGAF?

To schedule architecture meetings efficiently
To comply with project management methodologies
Because stakeholders focused on different time horizons have different concerns that require different architectural responses (Correct answer)
To plan architecture team vacations

Correct answer: Because stakeholders focused on different time horizons have different concerns that require different architectural responses

Stakeholders with short time horizons (operational) have different concerns than those with long time horizons (strategic), requiring architects to tailor their approach and deliverables accordingly.

Question 4: What is the relationship between Architecture Governance and IT Governance in TOGAF?

Architecture Governance is a subset of IT Governance, which is itself a subset of Corporate Governance (Correct answer)
IT Governance reports to Architecture Governance
They are the same thing with different names
They operate independently with no relationship

Correct answer: Architecture Governance is a subset of IT Governance, which is itself a subset of Corporate Governance

In TOGAF's governance hierarchy, Architecture Governance operates within and supports IT Governance, which in turn operates within Corporate Governance.

Question 5: What function does the Architecture Board serve inside TOGAF?

To provide guidance and direction for the architecture development process (Correct answer)
To manage the architecture repository
To oversee the implementation of the enterprise architecture
All of the above

Correct answer: To provide guidance and direction for the architecture development process

ToGAF's Architectural Board is in charge of giving the architecture development process direction and guidance. It serves as the organization's governing body, ensuring the enterprise architecture aligns with its objectives and goals. It also offers the required oversight to ensure the architecture is created and maintained consistently.

Question 6: How does TOGAF approach security architecture in the ADM?

Security is only relevant in Phase G (Implementation Governance)
Security concerns are integrated across all ADM phases as a pervasive concern affecting business, data, application, and technology domains (Correct answer)
Security is addressed only in Phase D (Technology Architecture)
Security is handled separately outside the ADM

Correct answer: Security concerns are integrated across all ADM phases as a pervasive concern affecting business, data, application, and technology domains

TOGAF treats security as a pervasive concern that must be addressed across all ADM phases and all four architecture domains (Business, Data, Application, Technology).

Question 7: What does the TOGAF architecture repository mean?

A database containing the enterprise architecture artifacts
A methodology for developing the enterprise architecture
A collection of documents and models that describe the enterprise architecture (Correct answer)
A set of tools and techniques for developing the architecture

Correct answer: A collection of documents and models that describe the enterprise architecture

In TOGAF, an architecture repository comprises models and documentation listing enterprise architecture. The repository houses all the products of the architecture development process and provides information for planning and decision-making.

Question 8: In TOGAF, what is the relationship between 'Architecture Principles' and security constraints during Phase B (Business Architecture)?

Principles are only relevant for technology decisions
Architecture Principles do not apply to Business Architecture
Business Architecture ignores security until Phase D
Security-related Architecture Principles constrain what business processes and capabilities can be designed in Phase B (Correct answer)

Correct answer: Security-related Architecture Principles constrain what business processes and capabilities can be designed in Phase B

Security-related Architecture Principles apply from Phase B onwards, constraining business process design to ensure inherent security is considered in business architecture decisions.

Question 9: Which ADM phase produces the detailed Implementation and Migration Plan?

Phase D
Phase E
Phase G
Phase F (Correct answer)

Correct answer: Phase F

Phase F (Migration Planning) produces the detailed Implementation and Migration Plan, prioritizing projects and defining transition architectures.

Question 10: Which TOGAF content metamodel concept captures the difference in architectural elements between a Baseline and Target Architecture?

Gap (Correct answer)
Risk
Assumption
Constraint

Correct answer: Gap

A Gap in TOGAF represents a difference identified between the Baseline Architecture and the Target Architecture that must be addressed in the transition plan.

Question 11: What neither constitutes an enterprise architecture component nor a domain?

Service Oriented Architecture (Correct answer)
Business Architecture
Information Architecture
Application Architecture

Correct answer: Service Oriented Architecture

Explanation: <br> Service Oriented Architecture (SOA) is actually a component and a domain of enterprise architecture. It is an architectural approach that emphasizes the design, development, and use of services to enable the integration and interoperability of different systems within an enterprise. SOA provides a framework for organizing and aligning various IT resources and applications to support business processes and goals.

Question 12: How does TOGAF recommend handling 'residual risk' after mitigation strategies are applied?

Residual risk is always eliminated through further mitigation
Residual risk is formally accepted and documented with approval from appropriate governance authorities (Correct answer)
Residual risk is transferred to the vendor
Residual risk is ignored if below a certain threshold

Correct answer: Residual risk is formally accepted and documented with approval from appropriate governance authorities

TOGAF recommends formally accepting residual risk (risk remaining after mitigation) with documented approval from appropriate governance authorities, creating an audit trail.

Question 13: In the Architecture Repository, what distinguishes an 'Architecture Metamodel' from other components?

It lists approved software products
It defines the organizationally tailored application of TOGAF and the relationships between architecture elements (Correct answer)
It contains compliance assessment results
It stores completed architecture deliverables

Correct answer: It defines the organizationally tailored application of TOGAF and the relationships between architecture elements

The Architecture Metamodel documents the specific application of an architecture framework, including entity types, relationships, and the tailored metamodel for the organization.

Question 14: What are the three categories of content defined in the TOGAF Architecture Content Framework?

Views, Viewpoints, and Perspectives
Deliverables, Artifacts, and Building Blocks (Correct answer)
Phases, Gates, and Reviews
Goals, Objectives, and Principles

Correct answer: Deliverables, Artifacts, and Building Blocks

The TOGAF Architecture Content Framework organizes architecture work products into three categories: Deliverables, Artifacts, and Building Blocks.

Question 15: What is the primary purpose of the TOGAF Architecture Content Framework?

To specify the communication channels between architects and stakeholders
To define the precise sequence of activities performed in each ADM phase
To establish governance approval processes for architecture decisions
To provide a structural model for categorizing and organizing architecture work products (Correct answer)

Correct answer: To provide a structural model for categorizing and organizing architecture work products

The Architecture Content Framework provides a structural model for categorizing the types of architectural work product and enables consistent definition and organization of deliverables.

Question 16: Which of the following is classified as an Architecture Artifact rather than an Architecture Deliverable in TOGAF?

Architecture Definition Document
Application Communication Diagram (Correct answer)
Architecture Vision
Statement of Architecture Work

Correct answer: Application Communication Diagram

An Application Communication Diagram is an artifact — a work product used to describe or document an aspect of the architecture, not a contractually specified deliverable.

Question 17: What is 'Identity and Access Management (IAM)' in the context of TOGAF architecture?

A compliance reporting system
A key security capability that can be defined as an Architecture Building Block ensuring appropriate access controls across all architecture domains (Correct answer)
A HR system for managing employee records
A network management tool

Correct answer: A key security capability that can be defined as an Architecture Building Block ensuring appropriate access controls across all architecture domains

IAM is a cross-cutting security capability in TOGAF architectures, typically defined as an ABB and implemented as SBBs providing consistent access control across business, application, and technology layers.

Question 18: Which TOGAF artifact catalogs all the software applications in an enterprise along with their ownership, functionality, and lifecycle status?

Application Portfolio Catalog (Correct answer)
Business Footprint Diagram
Technology Standards Catalog
Actor/Role Matrix

Correct answer: Application Portfolio Catalog

The Application Portfolio Catalog is an Information Systems Architecture artifact that lists all known applications with their ownership, key functionality, and lifecycle status.

Question 19: In TOGAF governance, what is a 'Dispensation'?

A type of architecture deliverable
An approval to proceed with a project
A formal exemption allowing a project to deviate from the defined architecture within defined constraints (Correct answer)
A budget allocation for architecture activities

Correct answer: A formal exemption allowing a project to deviate from the defined architecture within defined constraints

A Dispensation is formal permission granted by the Architecture Board allowing a project to deviate from the defined architecture, typically time-limited and with conditions.

Question 20: You work as a consultant for the chief designer of a low-cost private airline. An essential international airport serves as its principal base. It travels to 65 domestic destinations and nine countries in Europe, the Middle East, and Asia-Pacific. The airline has been given the go-ahead to merge with another foreign carrier, expanding its market reach and allowing it to supplement its key routes with connecting flights from critical international destinations. An enterprise architecture program has been started with TOGAF 9 as the approach and guiding framework to incorporate the new merger. The CIO sponsors the event. According to the Chief Architect, this application should employ iteration with the ADM. The CIO has underlined the need to make sure that the architecture is adopted throughout the organization when the program enters Phase A of the initial iteration of an Architecture Capability cycle. At this point in the program, you have been asked to describe how you would locate and interact with the stakeholders.

You would identify key stakeholders across both merged airlines. You would classify their positions and influence, recording the results in a stakeholder map. You would then focus on key stakeholders ensuring that you identify the most relevant viewpoints for each stakeholder and validate that their concerns are being addressed (Correct answer)
Concentrate on stakeholder communications to promptly deliver targeted information to the appropriate stakeholders. To ensure they are informed about the main components of the architecture and have the chance to comment, you would create a communications strategy
In Phase A, you would carry out a pilot project to show the stakeholders that the methods offered by your preferred providers were technically feasible. The statement of work would be finished, and an architecture contract would be issued to your suppliers once the stakeholders have confirmed that the method satisfies their criteria
With the parties affected by the merger, you will run a number of business simulations to see which parties share your perspective (likely to block the initiative and which are likely to support it). You would choose the most pertinent points of view and confirm them with the necessary parties

Correct answer: You would identify key stakeholders across both merged airlines. You would classify their positions and influence, recording the results in a stakeholder map. You would then focus on key stakeholders ensuring that you identify the most relevant viewpoints for each stakeholder and validate that their concerns are being addressed

Explanation: <br> The method TOGAF suggests for locating and involving the essential stakeholders in Phase I is stakeholder analysis and mapping. A significant product result that supports other outputs at this phase is the Stakeholder Map.

Question 21: In the ADM, what is the role of Architecture Principles during Phase B, C, and D?

They replace the need for gap analysis
They define the technology standards only
They are created for the first time in each phase
They guide and constrain the architecture decisions made in those phases (Correct answer)

Correct answer: They guide and constrain the architecture decisions made in those phases

Architecture Principles established in the Preliminary Phase and Phase A guide and constrain all subsequent architecture development.

Question 22: According to TOGAF, which of the following is NOT one of the three recognized types of Architecture Artifacts?

Frameworks (Correct answer)
Matrices
Diagrams
Catalogs

Correct answer: Frameworks

TOGAF defines three types of artifacts: Catalogs (lists of things), Matrices (relationships between things), and Diagrams (pictures of things); Frameworks are not an artifact type.

Question 23: What is an Architecture Viewpoint in TOGAF?

An alternate version of the Architecture Definition Document for different stakeholders
A physical location used to conduct architecture review board sessions
A personal perspective adopted by the Chief Enterprise Architect
A specification of conventions for constructing a particular kind of architecture view (Correct answer)

Correct answer: A specification of conventions for constructing a particular kind of architecture view

An Architecture Viewpoint is a specification of the conventions for a particular kind of architecture view, defining how it is to be constructed and used.

Question 24: What does the Architecture Development Method (ADMfirst )'s phase entail?

Architecture Landscape
Architecture Vision (Correct answer)
Architecture Governance
Architecture Requirements

Correct answer: Architecture Vision

The Architecture Vision phase of the ADM is where the enterprise architecture's high-level goals and objectives are developed.

Question 25: How does TOGAF recommend integrating compliance requirements (e.g., regulatory, legal) into the architecture?

Compliance requirements should be captured as architecture requirements and constraints early in the ADM, influencing architecture decisions (Correct answer)
Compliance only affects the Technology Architecture domain
Compliance is handled by the legal team separately from architecture
Compliance is addressed only after the architecture is fully defined

Correct answer: Compliance requirements should be captured as architecture requirements and constraints early in the ADM, influencing architecture decisions

TOGAF recommends treating regulatory and compliance requirements as architecture constraints captured early in the ADM (Phase A/B) so they influence all subsequent architecture decisions.

Question 26: How does TOGAF recommend documenting the security implications of 'Architecture Decisions' made during the ADM?

Architecture decisions do not need to address security
Architecture Decision Records should capture the security trade-offs and implications of each significant architecture decision (Correct answer)
Security implications are documented separately by the security team
Security implications are only documented in the final Architecture Definition Document

Correct answer: Architecture Decision Records should capture the security trade-offs and implications of each significant architecture decision

Architecture Decision Records in TOGAF should explicitly capture the security trade-offs, constraints, and implications of each significant decision made during the ADM.

Question 27: What is the TOGAF concept of 'Fitness for Purpose' in the context of Architecture Contracts?

The project team has the required certifications
The IT system meets minimum performance benchmarks
The solution is built using approved vendor products
The architecture deliverable meets the agreed criteria and is suitable for its intended use (Correct answer)

Correct answer: The architecture deliverable meets the agreed criteria and is suitable for its intended use

Fitness for Purpose in Architecture Contracts means that the deliverable meets the agreed quality criteria and is genuinely suitable for its intended architectural use.

Question 28: What is the Solutions Continuum in TOGAF?

A vendor selection process
A population of the Architecture Continuum with actual implementations, from generic products to organization-specific solutions (Correct answer)
A testing and validation framework
A schedule of solution delivery phases

Correct answer: A population of the Architecture Continuum with actual implementations, from generic products to organization-specific solutions

The Solutions Continuum represents actual implementations corresponding to the levels of the Architecture Continuum, from generic Foundation Solutions to Organization-Specific Solutions.

Question 29: What is a key governance challenge that the TOGAF Architecture Board must balance?

Minimizing the number of architecture phases used
Ensuring all projects use the same technology vendor
Maximizing the number of dispensations granted
Balancing architectural consistency and control with the need for business agility and project pragmatism (Correct answer)

Correct answer: Balancing architectural consistency and control with the need for business agility and project pragmatism

The Architecture Board must balance the need for architectural consistency and standards compliance with the business need for agility, speed, and pragmatic project delivery.

Question 30: What is the role of the 'Chief Architect' or 'Lead Architect' in TOGAF governance?

To write all architecture deliverables personally
To approve all technology purchases
To chair the Architecture Board and oversee the architecture governance process (Correct answer)
To manage IT vendor contracts

Correct answer: To chair the Architecture Board and oversee the architecture governance process

The Lead/Chief Architect typically chairs the Architecture Board and is responsible for overseeing the architecture governance process and ensuring architecture quality.

Question 31: Which of the following is not a preliminary ADM architecture concept example?

Modularization of system and technology
All data/information in system and technology is secured and protected
Acquire new system and technology i the market every year (Correct answer)
All business service can be access via web/online

Correct answer: Acquire new system and technology i the market every year

Explanation: <br> "Acquire new system and technology in the market every year" is not an example of an architecture principle in the ADM preliminary phase. Architecture principles are fundamental guidelines and rules that inform the decision-making process during the development of enterprise architecture. They help ensure consistency, coherence, and alignment with the organization's goals and strategies.

Question 32: What is a 'Business Scenario' in TOGAF, and when is it used?

A user story in agile development
A technique used to identify business requirements and potential architecture solutions by describing business problems (Correct answer)
A financial forecast for the business
A competitive analysis document

Correct answer: A technique used to identify business requirements and potential architecture solutions by describing business problems

A Business Scenario is a TOGAF technique for identifying and understanding the business requirements that an architecture must address by describing the business problem in context.

Question 33: Which ADM phase defines the target Business Architecture to support the Architecture Vision?

Preliminary Phase
Phase A
Phase B (Correct answer)
Phase C

Correct answer: Phase B

Phase B (Business Architecture) develops the Baseline and Target Business Architectures and performs gap analysis.

Question 34: How many ADM phases or processes are there?

12
10 (Correct answer)
11
13

Correct answer: 10

TOGAF's Architecture Development Method (ADM) consists of 10 phases: the Preliminary Phase plus Phases A through H (Architecture Vision, Business, Information Systems, Technology, Opportunities & Solutions, Migration Planning, Implementation Governance, and Architecture Change Management), with Requirements Management at the center. The other counts (11, 12, 13) overstate the number of phases.

Question 35: Which catalog in the TOGAF content metamodel documents all known technology standards and their lifecycle status?

Actor/Role Catalog
Application Portfolio Catalog
Data Entity Catalog
Technology Standards Catalog (Correct answer)

Correct answer: Technology Standards Catalog

The Technology Standards Catalog records all technology standards used across the enterprise, including their adoption and lifecycle status (emerging, current, retiring).

Question 36: What is a 'Value Chain' analysis in TOGAF, and how does it relate to stakeholder management?

A method for ranking architecture priorities
A financial analysis of IT investment returns
A supply chain management framework
A technique for understanding how business activities create value, helping identify key business stakeholders and their concerns (Correct answer)

Correct answer: A technique for understanding how business activities create value, helping identify key business stakeholders and their concerns

Value Chain analysis helps architects understand the business activities that create value, enabling better identification of key business stakeholders and their architecture concerns.

Question 37: In the TOGAF content metamodel, what entity represents an external or internal condition that motivates an organization to change its architecture?

Driver (Correct answer)
Principle
Constraint
Goal

Correct answer: Driver

A Driver in TOGAF is an external or internal condition that motivates an organization to change and is the foundation for defining Goals and objectives.

Question 38: In ADM Phase H (Architecture Change Management), what triggers a new ADM cycle?

Completion of all work packages
Annual mandatory review
Stakeholder sign-off on deliverables
A change request that requires a significant architecture update (Correct answer)

Correct answer: A change request that requires a significant architecture update

Phase H monitors for changes in the business or technology environment; a significant change triggers a new ADM iteration.

Question 39: In TOGAF, an Architecture View is best defined as:

An executive summary of ADM phase outcomes prepared for board review
A physical layout diagram of the IT infrastructure datacenter
A UML diagram created by software developers for system design
A representation of a system from the perspective of a related set of concerns (Correct answer)

Correct answer: A representation of a system from the perspective of a related set of concerns

An Architecture View is a representation of a system from the perspective of a related set of concerns, and is what architects use to communicate with specific stakeholder groups.

Question 40: Which ADM phase is responsible for populating the Architecture Repository with completed deliverables?

Only Phase A
All phases contribute to the Architecture Repository throughout the ADM (Correct answer)
Only Phase H
Only the Preliminary Phase

Correct answer: All phases contribute to the Architecture Repository throughout the ADM

The Architecture Repository is updated continuously throughout the ADM cycle as deliverables are completed in each phase.

TOGAF 9 Foundation Certification

The TOGAF 9 Foundation (Part 1) exam tests knowledge of TOGAF terminology, structure, and basic concepts including the Architecture Development Method (ADM), Architecture Content Framework, and Architecture Capability Framework. It is a closed-book exam administered by The Open Group.

Questions

60 min

Time Limit

60%

To Pass

Checking for saved progress...

Exam Rules

You can skip questions and return to them later
Flag questions for review before submitting
No feedback shown until you submit the entire exam
Unanswered questions count as wrong — answer everything
10 pretest questions are mixed in and don't affect your score
Timer auto-submits when time runs out
Your progress is auto-saved every 30 seconds

These practice questions were written with AI tools. They are not real exam questions. Exam facts are checked against the official sources listed below. Not reviewed by a subject-matter expert. Editorial policy

Sources & references

Exam facts on this page (fees, format, dates, passing scores) are checked against these official sources; the date is our last check. Editorial policy

pearsonvue.com — Test dates · verified Oct 2026
help.opengroup.org — Score release, retake policy, retake fee, exam format, passing score, time limit, test delivery · verified Oct 2026
