SketchUp is a 3D modeling software that may be used for various drawing applications. It is a part of Autodesk’s 3D modeling line and is the most downloaded design program on the market today, with over 10 million licenses sold. SketchUp is a result of many years of development from many companies. The first version of SketchUp was released in 2000. In 2004, it was bought by Google and was marketed. Like other 3D modeling programs, one should have a general understanding of 3D before starting. Also, SketchUp is extremely useful for people curious about mechanical and architectural designs.

SketchUp is so well-liked because of its design and ease of use. Users can easily modify the designs and create unique objects. The software is a 3D modeling application but can be used for 2D and 3D work. It allows people to create a variety of objects, including planes, solids (including platonic solids), surfaces, volume rendering, voxel rendering (i.e., like scanned images), and even interior design.

SketchUp Free Practice Test Online

SketchUp Certification

Taking SketchUp certification is an excellent way to increase your knowledge and ensure that you are prepared for potential careers in 3D Design. SketchUp is a visually expressive program with the power to design 3D models and visualize them in 2D through various layouts and views. These programs are perfect for architects, designers, or even handypersons who want to make their creations happen! Certification programs typically range from one week to two months long, depending on your level of experience. You will learn advanced techniques from 3D Modeling to sketching and problem-solving. Upon completing these programs, you will receive an official certification that can give you the edge you need to launch your career or explore a new creative path.

SketchUp Rotate Object

Rotation is a very common operation that can be easily performed. To rotate an object in SketchUp:

  • Open SketchUp
  • Go to View > Coordinates > Rotation Center
  • Place the cursor on any side of the object and press Z with your mouse button down to rotate.
  • Use the arrow keys on your keyboard to rotate the object.

The object can be rotated in all directions using this method, even if it is not properly aligned with the coordinate system’s origin point. This might be necessary for installation models or furniture to fit in their desired space correctly.

SketchUp Make Solid

A solid in SketchUp is any 3D object with a finite closed volume. The group or component must include just geometry, no other groups or components, and precisely two faces must share every edge in the group or component. To create a solid object, choose the raw geometry and right-click and select Make Group. To see whether your group or component is a solid entity, right-click it and choose Entity Info. The Entity Info dialog box’s upper-left corner shows if the selection is solid. You must add geometry to this entity if it is not solid. The easiest way to add geometry to your solid is to extrude the edges of the group or component into other objects.

SketchUp Mirror

SketchUp Mirror is a procedure that allows you to reflect any item to its opposite side for various reasons. These include checking out a blueprint or drawing, making an inverse image, making a template of something to be printed, etc. This application helps you make your drawing more realistic and vivid. To mirror an item using Mirror, pick it and then activate Mirror. Draw your mirror spot, and you’re done. The mirror spot is moved to that location when you reload your document. This allows you to use this function on any item.

Door Hinge SketchUp

Door hinge SketchUp is a 3d model that displays the geometry and dimensions of a door hinge. Here are the steps to make one in SketchUp:

  • Create a rectangular plate that is the same size as the flattened-out hinge.
  • Push/pull the plate to 3/16-in hinge thickness. Draw the hinge knuckle’s diameter and size.
  • Draw lines around the rectangle to divide the thickness of the plate.
  • Tap the Ctrl key using the Push/Pull tool to push the knuckle form through the plate to the other end.
  • To remove the plate’s thickness, use the Eraser Tool.
  • The knuckle must be separated between the hinge’s top and lower parts.
  • Draw a select box around all hinge sections using the Select Tool. Then, right-click on the selection and choose Intersect Selected from the menu. Then divide into five parts.
  • Remove the bottom portion of the hinge using the Eraser Tool. Make the top part into a component.
  • Make the bottom portion of the hinge into a component as well.
  • Create the screw holes and FHWS recess.
  • Because the halves are components, we may rotate them to display multiple hinge orientations.

How to make a Sphere in SketchUp?

To make a sphere, draw a circle on the ground plane and another perpendicular to the first with the same radius point. Here are the steps to make it:

  1. Draw a circle on the ground plane using the Circle tool.
  2. Hover the mouse cursor on the origin until it snaps to it, then move the cursor up the blue axis.
  3. Draw a circle perpendicular to the circle on the ground plane starting from the blue axis. To promote the inference, rotate the screen such that the green or red axis runs roughly left to right.
  4. Now, rotate the orbit to a side view and draw a second circle perpendicular to the first circle, beginning at its center. They should all have the same center radius.
  5. Select the circle’s edge on the ground plane using the Select tool.
  6. Click the second circle’s profile using the Follow Me feature. Your sphere is complete, and you may remove the circle from the ground plane.

Export Revit to SketchUp

Revit is an excellent program for BIM (building information modeling) and 3D modeling. Still, if your sketching skills are better than your CAD ability, you may want to export Revit models to SketchUp. There are two methods for exporting Revit to SketchUp.

Method 1

This method is the easiest because you don’t need any plugins or software to use the existing Revit. Ensure your model has been saved as a “DWG file” and not an “RVT file.” You can also try exporting to Autodesk DXF format. Open SketchUp, create a new document, and select File> Import from the menus. Select DWG Files from the drop-down list and choose Continue. Now you should be at a window to select the .dwg File you want to import into SketchUp. Click on Import, and your model will appear in SketchUp. If it doesn’t show up, click the “Use Model Location” button and find it there.

Method 2

This method requires a plugin, but it’s very easy to use. Just install the plugin in your Revit. Download it and install it. After installing the plugin, open your model in Revit. Go to Tools> Import> SketchUp and click on “OK.” Then your model will be imported into SketchUp.

SketchUp Pro

SketchUp Export as OBJ

Wavefront Technologies created the OBJ file format for their Advanced Visualizer program, and other 3D software companies have since embraced the open OBJ format.

It’s possible to export SketchUp models as OBJs with a few simple steps:

  1. Choose File, then click Export 3D Model. The Export Model dialog box is shown.
  2. Go to the folder where you wish to store your OBJ file.
  3. Select OBJ File (*.obj) from the drop-down menu.
  4. When you click Export, your OBJ file is stored where you specified.

SketchUp Move Object on Axis

After you’ve begun a move, touch an arrow key to lock an axis, which allows you to hover your mouse over any point in your model while keeping the entities you’re moving out of the way. Once you’ve locked onto the point, touch the arrow key again to release the axis lock, and your geometry will snap to that point instantly. Make careful not to move the mouse and then click to complete the move.

SketchUp Scale Object to Specific Size

There are two easy ways to scale an object in SketchUp to a specific size:

  1. To select the complete shape, triple-click on one of your object’s faces. Select the tape measure tool and measure the edge whose measurements you wish to adjust by clicking once at the beginning and once at the finish. Then, put the required dimension in the “length” box in the bottom right corner.
  2. Press the “enter” key on your keyboard. If you wish to resize the model, a dialog will display asking you. You won’t have to worry about mistakenly rescaling other items if you have one in the model. Go ahead and press the “yes” button. If there are additional items in your model, it will resize them all.

Edit Mesh in SketchUp

A Mesh is a collection of vertices, edges, and faces. Editing a mesh can involve deleting or adding vertices, edges, and faces. We must edit the model’s components while changing the mesh. Go to Edit and choose Solid Component at the bottom of the screen. Then, from the cascaded menu, choose Edit Component.

How to Snap Objects in SketchUp?

To snap objects in SketchUp, select one of these methods below:

  • Command+E – Easiest and fastest method. Select an object and press Enter. The object will be snapped to the nearest endpoint of a line, face, or another object.
  • Control+Command+E – Similar to the first method, except it snaps to midpoints instead.
  • Alt+C – Snaps selected objects to points you define by dragging a line segment between two points already drawn on the screen (or between 2 endpoints) so that your drawing is accurately scaled – Point A corresponds to reality (1 unit in length), Point B corresponds to your SketchUp model (x units in length).

SketchUp Green Axis

In SketchUp, the green axis is the vertical axis used to define the elevation of a face. It is also often used as a reference point when orienting an object in 3D space. The green axis has one end at the bottom of the model and then continues upwards, reaching its maximum height near the top of your 3D viewport. Note that this height is only visible in older versions of SketchUp, so you may not be able to see it on your computer screen if you are using SketchUp Pro 2018 or later. The green axis is necessary for SketchUp. When you import (or input) a 2D image into SketchUp and have a flat image, the green axis does not exist. Only when you place a 3D object into this 2D (flat) image does the green axis appear.

SketchUp Material Transparency

To make an item transparent, you must change the materials used on the object’s face. To do so, choose the paint bucket tool in the materials window. Then, use the menu or the eyedropper tool to browse the necessary material. You should be able to utilize the opacity slider to raise or decrease the opacity after you’ve picked the material. You can use either normal or set values on plugins as well. Some materials on your object will require this trick if they aren’t already fully transparent.

SketchUp Question and Answers

The user-friendly 3D modeling program Sketchup (formerly Google Sketchup) offers a large archive of user-generated models that may be downloaded. To help with all types of tasks, like creating furniture, making video games, 3D printing, interior design, and anything else you may think of, you can use it to draw (or import) models.

The simplest free 3D modeling program available online is called SketchUp Free.

The user-friendly 3D modeling tool SketchUp enables you to create and edit 2D and 3D models using the proprietary “Push and Pull” technique. Designers may extrude any flat surface into 3D objects with the Push and Pull tool. Simply click an object and begin tugging it until you are satisfied with what you see.

Yes! SketchUp is Free (non-commercial applications). Now that SketchUp is compatible with all current web browsers (so no IE), it may be used on Mac, Windows, Linux, and even Chromebooks.

In order to make a sphere, you must first draw a circle on the ground plane and then another circle with the same radius point that is perpendicular to the first. The shape is then transformed into a sphere by using the Follow Me tool to make it adhere to the initial circle on the ground plane.

Using CTRL + Move is the quickest way to repeat this. You can then scale negatively to mirror the original object once the replica is in place.

The solid model from Google Sketchup Pro can be transformed into orthographic views, presentation views, and other working drawings using Sketchup Layout. Using Google Sketchup Pro, the user will produce “Scenes” that are equivalent to the orthographic perspectives of a design (Front, Right Side, Left Side, Rear, etc.)

From $0 to $699, there are 4 pricing tiers for SketchUp. SketchUp also provides a free trial.
View the various pricing editions listed below to determine which edition and features fit your needs and budget.

  • SketchUp Free – $0.001 Seats Per Year
  • SketchUp Shop Subscription – $119.001 Seats Per Year
  • SketchUp Pro Subscription – $299.001 Seats Per Year
  • SketchUp Studio Subscription – $699.001 Seats Per Year

Press the Ctrl key while using the Move tool to create copies (Option on the Mac). The spacing and number of copies can be easily adjusted in SketchUp. Once the first copy has been created, you can specify the number of additional copies and the distance between them.

Select Arrange > Align, and then from the resulting submenu, choose Vertically or Horizontally to align two or more chosen objects vertically or horizontally. Choose Arrange > Center, and then from the submenu, pick Vertically on Page or Horizontally on Page to center two or more selected elements.

Transferring a model can be done in two different ways. First, you can use a plugin; second, you can export to a DWG file and then import it into SketchUp. Each approach has advantages and disadvantages. When using the plugin, the model keeps its original components but loses editability. Maximum editability is retained when exporting to DWG, however no materials are saved.

Select the object you want to rotate using the Select tool (Spacebar). By using the (Q) key on your keyboard, turn on the Rotate tool. Click the location where you want to rotate from, however this time drag outward perpendicular to the plane you want to rotate on while holding down the mouse button.

Pre-select the object or objects you wish to scale before launching the Scale Tool by pressing (S). The objects you picked will have a yellow box surrounding them and a number of green “handles” that you may click and drag to change their size. To grasp the fundamentals of the Scale Tool, try dragging the various handles.

Pick the group entity and select Edit > Ungroup from the menu bar if you no longer require the group. You can also context-click the chosen item to bring up a menu, then select Ungroup. Once more, each member of the group is a distinct entity.

SketchUp Pro Subscription – $299.001 Seats Per Year

Just pick out the objects you want to flip. Next, choose Top to Bottom or Left to Right under Arrange > Flip. The SketchUp model entity and the dimension are both selected (left) in the following image, and they are both then flipped from top to bottom (right).

By selecting Window > Model Info > Units in SketchUp Desktop, you can alter the units. All of the model’s measurements will be automatically adjusted to match.

  • Click Extensions > Extension Manager in SketchUp. A window for Extension Manager appears.
  • Select Install Extension from the menu.
  • Locate the.rbz file saved on your computer, choose it, then click OK (Microsoft Windows) or Open in the ensuing Open dialog box (Mac OS X).
  • Click Yes to continue and install your extension when SketchUp prompts you to only install extensions from reputable sources. (This presupposes that you actually believe the source of your extension.)

In SketchUp, you may extrude a triangle along a circular path or resize a cylinder face to produce a cone-shaped shape.
Follow these procedures to turn a cylinder into a cone:

  •  Create a circle using the Circle tool.
  • To extrude the circle into a cylinder, use the Push/Pull tool.
  • Choose the Move button ().
  • Click a cardinal point on the cylinder’s upper edge. A cardinal point serves as a resize handle when it is in line with the red or green axis. Hover the Move tool cursor over the upper cylinder’s edge to locate a cardinal point; when the circle’s edge highlighting vanishes, the location has been determined.
  • Move the edge toward the center until it condenses into a cone’s point.
  • To finish the cone, click in the center as seen in the picture on the left.
  •  Commence by creating a simple box sketch of the structure.
  • Draw lines to indicate the eaves of the roof at one end of the structure. This determines how far the roof must reach from the building’s edge to keep out rain and other elements.
  • Establish the vertical that will result in the desired roof slope. The x and y axes are used to define slopes vertically and horizontally, respectively. For instance, a 4/12 pitched roof rises 4 inches on the y axis for each 12 inches on the x axis.
  • After representing the eaves with lines, define the roof slope with more lines to create your first gable end.
  • Create a path by drawing central lines across the top of the building to indicate where the roof will be.
  • Choose the “follow me” tool after choosing the central line or lines.
  • When you click on the gable end, you’ll see that the roof is created by it following the course of the central line you’ve selected.
  • Choose “reverse faces” to create the roof’s slope, then tweak it as necessary.

Choose Unhide from the context menu after selecting the hidden geometry. (When selected geometry is hidden, the menu item labeled Hide turns to Unhide.)

Trimble is the owner of SketchUp. On June 1st, 2012, Trimble Navigation (now Trimble Inc.) purchased SketchUp from Google.

Simply open the SketchThis box, select the desired cabinet, and drag it into your model. With Sketchup’s ingenious dynamic components feature, you may modify several key features, including the size of your kitchen, the design of the drawers and doors, the toe kick detailing, and much more. Since the modifications are dynamic, you get to enjoy a seamless workflow and exciting quick results.

Window > Default Tray > Soften Edges should be chosen. Alternately, right-click on your selection and select Soften/Smooth Edges. In any case, the dialog box for Softening Edges will come up as seen in the picture. To adjust the maximum size of all angles that will be rounded or softened, click and drag the Angle between normals slider.

  •  Press the spacebar, then choose all of the structures that you haven’t yet stamped onto the ground. Hold down Ctrl to choose several (Shift on the Mac OS).
  • Pick the Drape tool at this point. On the terrain, click.
  • Without changing anything else, SketchUp imprints the seven rectangles onto the landscape.
  • The 2D map is finished for the time being, so group it and then conceal it.
  • Choose every piece of terrain and make it a component.

SketchUp is simple to use and easy to understand.

No. A surface modeler, SketchUp. If you modified the length of an edge in SketchUp that is connected to other geometry that needs to follow the change, it would be a contradiction (and there are infinite possiblities, e.g. distort directly neighboring geometry or move whole parts).

Any elementary or secondary school that has signed up for G Suite for Education is able to use SketchUp for Schools, a free version of the program. Students all across the world now have access to free, user-friendly 3D modeling tools with SketchUp for Schools, enabling early skill development and creative expression.

PRO Users of SketchUp Pro can import or export CAD files using the.dwg or.dxf file extensions.

A single person is connected to a single-user license or sign-in subscription. The license can be installed on as many as two computers, but only one of those PCs can run SketchUp Pro at any given time.

A minimum of iPadOS 15 or higher is needed for SketchUp for iPad, which is compatible with a variety of iPad models. Take a look at the System Requirements for additional details. Wherever Your Models Are: It’s simple to open, distribute, and manage your models using SketchUp for iPad.

To build 3D things in a 2D setting, utilize the 3D modeling application Sketchup. Even for a beginner, Sketchup provides all the tools required to produce professional and high-quality outputs, whether you intend to model for 3D printing or for other uses.

The Windows Fonts folder is where you put new fonts because SketchUp uses those there. Write “Font Settings” into the Windows search box. Add fonts directions should be followed.

Any material in the Materials list will display a context menu when you right-click on it. The material can be applied to a layer or the currently chosen item. To apply the material, use the Apply To Layer option and choose any layer.

Use the text tool in Sketchup to obtain area calculations. Simply click on the face you wish to measure after choosing the “text” tool from the top menu bar. You will automatically be shown the size of that region.

Choosing the Edit tab. Under the tab name, click the Background Settings icon (). Select the ground, sky, and backdrop elements that you want.

Select the Materials option from the right-hand menu, then the chosen material, then selecting the Edit button to alter the material’s color.

  • Open your drawing in SketchUp.
  • From the Guide toolbar or the “Tools” menu, select the “Section Plane” tool.
  • To cut into a portion, click on it. To reverse the cut, press “Esc”.

If the Layers panel does not appear on the screen, choose Window > Layers if it is not already open. A single-page icon in the far-right column denotes a regular layer, whereas a four-page icon denotes a shared layer.

Search for the SketchUp model of your choosing and click to download by selecting the library option in the top left-hand corner of the GrabCAD homepage.

Pick the entity to be explode, perform a context click, and then select Explode Curve from the menu that displays. You can see a polygon in the figure that is going to break apart into its component pieces.

Update your software, graphics card drivers, and clear up some disk space by eliminating superfluous files if you’re having issues with SketchUp’s responsiveness. You might need to update your system memory if that doesn’t work.

To flip your geometry, use the following actions: The geometry you want to flip should be selected using the Select tool (). Select Flip Along from the context menu of your choice.

You can do this by taking the following actions:

On Windows, choose:
Check on Large Tool Set in View > Toolbars.
On a Mac, choose:
View > Large Tool Sets > Tool Palettes

Choose File > Geolocation > Add Location from the menu bar or click the Add Location tool () on the Location toolbar. Enter the address or junction of the location of your preferred terrain in the Add Location window that displays. When you click the Search button, a window with an aerial view of your area opens.

On the right side of the window, select the Views icon. Afterward, decide between Parallel Projection and Perspective. Then, by clicking on a home icon, pick one of the 9 typical views, such as Top, Front, Iso, etc.

  • Select each entity you wish to be a part of your group using the Select tool ().
  • From the menu bar, choose Edit > Group. Alternately, you can select Group from the pop-up menu by context-clicking the chosen item. The selection is grouped into all of its component parts within a bounding box
  •  Launch Google Sketchup and select the project you wish to add a photo to.
  • From the “File” menu, choose “Import.” Select “All Supported Image Types” from the drop-down box under “Files of Type” Click “Use As Image” or “Use As Texture” after selecting your image in the dialog box to insert it as an image or use it as a texture for an already-existing object. To open the image in your project, click “Open.”
  • Position your cursor over the area or thing you wish to insert the image into. To make an image smaller or larger, click the desired spot and then move your cursor inward or outward. The image will look tiled and reshaped on the item if you chose “Use As Texture” and the image is a different size or form than the chosen object.
  • To complete adding the image to your SketchUp model, click the region once more.

Select the RBZ file you just downloaded by choosing Window Preferences (Microsoft Windows) or SketchUp Preferences (Mac OS X) Extensions Install Extension inside of SketchUp. Voila! The extension is installed by SketchUp.

Choose the Join tool (), which is available in the standard toolbar or by going to Tools > Join. With the Join tool selected, click an edge on each piece. As you click, a blue outline flashes and the shape starts to take on the fill color of the first shape you clicked.

With the Polygon tool, an equilateral triangle can be created. Grab the device, enter 3, and then type 3. By clicking to set the triangle’s center and dragging out, you can draw it. Draw the distance from the center to the edge by holding down Ctrl (Option on a Mac) while entering the distance from the center to a corner.

Make a sizable rectangle. The edges of your smaller irregular polygon should be based off of that. You could draw one of those if it just has to deviate slightly from a regular polygon, then pick it, right-click > context-menu > Explode, to separate the perimeter’s edges.

From the built-in toolbar or by choosing Tools > Text, choose the Text tool (). Click and drag to define the box’s size, then let go of the mouse button to create a bounded text box. Simply click where you want to start typing to create an unlimited text area.

  •  Make the platform from which you will need to construct the steps. It will probably have to be perpendicular to a structure.
  • Draw two 12″ lines that are parallel to one another. Attach them to the framework you developed.
  • Repeatedly copy them and attach them. Continue doing this until they reach the “floor.”
  • Draw a line from the bottom of the steps back up the direction they came. To halt it in the proper place, use the inference point.
  • To complete the surface, draw a line from that location to the start of the stairs. The surface will fill in when you finish the “loop.”
  • To make the stairs wider, select the Push/Pull tool. To match the platform’s width, use inference.

To purge of anything you have lying around, Select Statistics from the sidebar on the left after choosing Window > Model Info, and then click the Purge Unused option.

Choosing the Edit tab. Under the tab name, click the Background Settings icon (). Select the ground, sky, and backdrop elements that you want.

Toggle the icon. The opportunity to choose the % reduction will be shown in a box. This will regulate how many faces are removed from the object. You can select a percentage between 40 and 60 percent if you plan to place the object anywhere in the middle of the composition.

Go to styles under the SketchUp model tab, where you will see a background checkbox.
